Product Description

**NOTE: Secondary image shows freezer unit with lit sign panel**

The unit is energy efficient, promising up to 35% in power savings over traditional solutions. It was designed with large internal volume and shelf space requirements in mind.

• Up to 35% power savings
• EC fan motor significantly reduces the systems heat load, resulting in reliability, energy efficiencies and a quieter operation.
• Large internal volume and shelf space.
• LED lighting as standard.
• Minimise footprint as cabinets can be placed against a wall.
• Electronic controller with digital temperature display.
Improved airflow design and reduced operating temperatures.
• Available in white and stainless steel
• Optional: Lit Sign Panel

CABINET SPECIFICATIONS
Refrigeration system: Top mounted SKOPE Cyclone freezer unit with electronic controller
Electronic Controller: CAREL ir33 electronic controller
Refrigerant: R404A / 700 g
Nominal capacity: 752 Watts @ -30°C evaporator, 50°C condenser
Cabinet internal volume: 610 litres
Cabinet temperature range: -18°C to -21°C in 40°C
Drainage: No plumbing required
Electrical: 220-240 Volts a.c. 50 Hz, single phase supply, 7.5 Amps
Internal lighting: 1 x side light: 22 Watt T8 LED tube (ø26 x 1500mm)
Sign lighting: Not as standard. Optional vented lit sign panel: 1 x 9 Watt T8 LED tube (ø26 x 600mm)
Internal door opening size: 1 door opening: 1570mm high x 620mm wide
Doors: 1 x self-closing, triple glazed, heated, toughened safety glass swing door
Shelves: 5 x adjustable height wire shelves: 620mm wide x 475mm deep
Total weight: 198 kg

Cabinet dimensions:
External: 740W x 710D x 2195H
Internal: 640W x 555D x 1570H
Floor area: 0.53m2
Insulation: 50mm polyurethane foam

Specifications
Product height
1570 mm
Product depth
475 mm
Product width
620 mm
Packaging height
1884 mm
Packaging depth
570 mm
Packaging width
744 mm
Packaging weight
237.6 kg
Electrical power
752W
